| ماڈل | WH-6-5 | WH-6-6 | WH-6-12 | |
| آؤٹ پٹ | ڈی سی آؤٹ پٹ وولٹیج | 5V | 6V | 12V |
| Output Voltage Tolerance | +1% | +1% | +1% | |
| شرح شدہ آؤٹ پٹ کرنٹ | 1A | 1A | 0.5A | |
| Output Current Range | 0~1A | 0~1A | ,0~0.5A | |
| آؤٹ پٹ پاور | 6W | 6W | 6W | |
| لہر اور شور | 50mVp-p | 50mVp-p | 50mVp-p | |
| DC Voltage Adjustable Range | -9% ~ +10% | +10% | +10% | |
| Start, Rise, Hold Rime | 200ms, 50ms, 20ms/230VAC | |||
| Input | ان پٹ وولٹیج کی حد | 170-264VAC; 47-63Hz，235-373VDC | ||
| AC ان پٹ کرنٹ | 0.35A/230VAC | |||
| کارکردگی | 78% | 78% | 80% | |
| امپلس کرنٹ | Cold start current 30A / 230VAC | |||
| رساو کرنٹ | ＜0.5mA/240VAC | |||
| تحفظ | Overload Protection | 110% – 135% of rated output power start overload protection | ||
| Protection Mode | fold type current limit, automatic recovery after removal of abnormal load conditions | |||
| Environmental Science | Working Temperature And Humidity | -10℃ ~ +60℃; 20% ~ 90% RH (please refer to load derate curve) | ||
| Storage Temperature And Humidity | -20℃ ~ +85℃; 10% ~ 95% RH non condensing | |||
| Seismic Resistance | 10~ 500Hz, 2G 10min. / 1 cycle, duration 60min, each axis | |||
| Security | دباؤ کی مزاحمت | Input-output room: 1.5kVac Input and ground: 1.5kVac Output and ground: 0.5kvac |
||
| Insulation Resistance | Input-output room: input and ground, output and ground: 100M ohms/ 500VDC | |||
| دیگر | وزن | 0.080kg 76*41*28(L*W*H) | ||
| پیکنگ | 100pcs | |||
6W Switching Power Adapter AC/DC 5V/1A 6V/1A 12V/0.5A Wall-mount Interchangeable Plug US/EU/UK/AU
Our components are genuine and of the highest quality, boasting a low DC ripple, reliable work efficiency, strong interference resistance, low operating temperature, pure copper core material for enhanced oxidation and corrosion resistance, and excellent durability.
This upgraded material offers maximum fire protection and temperature resistance. The shell is constructed from PC-based, environmentally-friendly fireproof materials to ensure strength and durability with confidence. Additionally, the material is heat resistant for an added level of safety.Protection: Short circuit/Overload /Over Voltage/Over Temperature.اگر آپ کے کوئی سوالات ہیں تو، براہ کرم ہم سے رابطہ کرنے میں سنکوچ نہ کریں۔ ای میل: [email protected]
