48V to 24V 5A 120W DC to DC Converter

The WEHO WH-C241240 is a formidable DC-DC converter, delivering a massive 480W of power for the most demanding 12V systems. It steps down a 24VDC input to a powerful 12VDC, 40A output, all while maintaining an excellent 95% efficiency. This unit is built for tough jobs, featuring a robust, fully sealed, and waterproof housing and heavy-duty 12AWG wiring. Its enhanced safety features include a trip-point overcurrent protection at 150% load and require a 42A fuse for complete short-circuit protection. With a proven reliability of over 100,000 hours, it is the ultimate solution for high-current, critical applications.
If you have any questions, please do not hesitate to contact us at Email: [email protected]
Our professionals will respond to you as soon as possible.

Download Request A Quote

Description

Summary
Rated output: power 240W
Input voltage: 48VDC

General specification

	Model
Specification	WH-C482410
Rated Output Power (W)	240W
Rated Input Voltage (V)	48VDC
Rated Output Voltage (V)	24VDC
Voltage Range (V)	30V-60VDC
Starting Voltage (V)	30VDC 100% load
No-load Power Consumption (W)	< 3W
Efficiency	96％
Voltage (V)	24VDC
Current (A)	10A
Voltage Tolerance	1％
Load Regulation	3％
Wave (MVP-p)	250 mV external 22 uF capacitor ESR < 0.1 Ω 100 KHZ
Over-current Protection	In the case of rated output, if the current exceeds 120% of the rated current, the overcurrent protection will act and it will automatically recover after the overcurrent disappears.
Short circuit protection	Equivalent to a maximum current of 12A and an output voltage of 0V
Input-Output	Non-isolated
Waterproof	Fully sealed and waterproof
Dimension	747432mm
N.W	300 g
Cooling Method	Natural Method
Rated Temperature Rise (℃)	45℃
Reliability	＞100000h
Wire Indicator	Input Positive (red), Input Output Negative (black), output positive (yellow), lead length = 160 mm ± 10mm
