High Quality Best Sell 12V 8A 96W Power Supply Adapter For CCTV LCD Display LED

This 96W power supply adapter adjusts input voltage from 100 to 240 volts AC.

The adapter supports a DC output voltage of 12 or 24 volts, with a tolerance of 1%.

It also offers an output current range of 0-7A or 0-4A and an output power of 96 watts.

It has protections against over-voltage, over-current, and short-circuit, making it a safe and efficient way to power your devices.

If you have any questions, please do not hesitate to contact us at Email: [email protected].

Model WH-96-12 WH-96-24
Output DC Output Voltage 12V 24V
Output Voltage Tolerance +1% +1%
Rated Output Current 8A 4A
Output Current Range 0~7A 0~4A
output power 96W 96W
Ripple And Noise 80mVp-p 80mVp-p
DC voltage adjustable range +10% +10%
Start, Rise, Hold Time 200ms, 50ms, 20ms/230VAC
Input Input Voltage Range 170-264VAC; 47-63Hz, 235-373VDC
AC Input Current 0.35A/230VAC
Efficiency 82% 82%
Impulse Current Cold start current 30A / 230VAC
Leakage Current <0.5mA/240VAC
Protection Overload Protection 110% – 135% of rated output power start overload protection
Protection Mode Fold type current limit, automatic recovery after removal of abnormal load conditions
Environmental Science Working temperature and Humidity -10℃ ~ +60℃; 20% ~ 90% RH (please refer to load derate curve)
Storage Temperature And Humidity -20℃ ~ +85℃; 10% ~ 95% RH non condensing
Seismic Resistance 10~ 500Hz, 2G 10min. / 1 cycle, duration 60min, each axis
Security Pressure resistance Input-output room: 1.5kVac
Input and ground: 1.5kVac
Output and ground: 0.5kvac
Insulation Resistance Input-output room: input and ground, output and ground: 100M ohms / 500VDC
Other Weight /
Packing /
