HDR-100 Industrial DIN-Rail Single-Output Power Supply
WeHo’s HDR-100 Industrial DIN Rail Single Output Power Supply is a reliable and rugged power solution for industrial automation and control applications, providing stable and efficient power to drive various industrial devices.
HDR-100 is a single-output DIN-rail power supply series. Confirm the exact output model, electrical ratings and applicable datasheet revision before ordering. Our products are equipped with various features to ensure their efficient and safe operation.That includes low no-load power consumption for energy savings, automated short circuits, overload and overvoltage protection, and other protective measures.If you have any questions, please do not hesitate to contact us at Email: [email protected]
- Description
Specification version notice: Published HDR-100 datasheets contain different electrical and temperature specifications. Confirm the exact model, hardware revision and applicable approved datasheet before selection or installation. The published datasheets list HDR-100-12, HDR-100-15, HDR-100-24 and HDR-100-48; confirm the required model and availability in the written quotation.
| Model | HDR-100-12 | HDR-100-15 | HDR-100-24 | HDR-100-48 |
| DC Output Voltage | 12V 0~7.5A | 15V 0~6.6A | 24V 0~4.16A | 48V 0~2A |
| Wave And Noise | 120mVp-p | 120mVp-p | 150mVp-p | 200mVp-p |
| Inlet Wire Stability | ±1% | ±1% | ±1% | ±1% |
| Load Stability | ±1.5% | ±1% | ±1% | ±1% |
| Efficiency | 85% | 86% | 88% | 88% |
| Adjustable Range For DC Voltage | ±1% | ±1% | ±1% | ±1% |
| Input Voltage Range | 85~264VAC 120~370VDC 47~63Hz | |||
| Impact Current | Cold start Current 30A/115VAC 60A/230VAC | |||
| Overload Protection | 105% -160% cut off the output, automatic recovery | |||
| Other Protection | Overcurrent protection / Short-circuit protection | |||
| Setup, Rise, Hold Up Time | 3000ms, 50ms/230VAC at full load 3000ms, 50ms/115VAC at full load | |||
| Withstand Voltage | I/P-O/P: 1.5kV | |||
| Isolation Resistance | I/P-O/P I/P-FG O/P-FG: 500VDC/100MΩ | |||
| Working Temperature | -10℃ ~ +50℃ | |||
| Dimension | 70x90x54.5mm | |||
| Weight | 0.27kg | |||
Feature HDR-100 Industrial DIN Rail Single Output Power Supply
Output selection: HDR-100 is a single-output series; output voltage and current depend on the exact model. Confirm the applicable ratings and operating conditions before selection.
Input Voltage Range: The HDR-100 power supply has a wide input voltage range, typically from 85VAC to 264VAC, making it compatible with a wide range of AC power sources commonly used in industrial environments.
DIN Rail Mounting: The HDR-100 power supply is designed to be mounted on a standard DIN rail, which is a common mounting method used in industrial control panels and cabinets. This allows for easy installation and integration into industrial control systems.
Efficiency: Efficiency varies by output model and operating conditions. Confirm the value in the applicable approved datasheet.
Protection Features: The HDR-100 power supply comes with various protection features to ensure reliable and safe operation. These may include overvoltage protection, overcurrent protection, short circuit protection, and thermal protection, which help safeguard the power supply and the connected devices from damage due to electrical faults.
Operating temperature: The linked published HDR-100 datasheet lists -10°C to +50°C. Confirm the applicable hardware revision, allowable load and installation conditions before use.
Model-specific documentation: Request the applicable compliance documents for the exact model, product revision and intended market. Confirm their scope and current status before ordering.
