AC TO DC smps 30W Dual output supply unit

WeHo’s D-30 Series is an AC/DC multi-output Power supply which standard model that offers the most cost-effective option when multiple voltages are required.

D-30 comes in an Enclosed case in dual.

WeHo focuses on producing high-quality power adapters, and stable output.

Automatic overload cut-off, over-voltage cut-off, automatic thermal cut-off, short circuit protection.

If you have any questions, please do not hesitate to contact us at Email: [email protected].

Output DC Voltage 5V 12V 5V 24V
Voltage Tolerance ±2% +3,-7% ±2% +3,-5%
Rated Current 4A 1A 2.2A 1A
Current Range 0.5-4A 0.1-1A 0.5-4A 0.1-1A
Rated Power 32W 32W 35W 35W
Ripple & Noise (Max) 50mVp-p 100mVp-p 50mVp-p 100mVp-p
DC Voltagefre Quency Range CH1+10, -5% CH1+10, -5% CH1+10, -5% CH1+10, -5%
Setup, Rise, Hold Time 200ms, 50ms, 30ms
Input Voltage Range 85132 VAC/170264VACselected by switch 4763 Hz120370VDC
AC Current 0.8A/115 V0.45A/ 230 V
Efficiency 72% 72% 74% 74%
Inrush Current Cold start18A/115V36A/230V
Leakage Current 0.5mA/240VAC
Protection Overload Protection 105%-150%Fold back current limiting recovers automatically
Environment Working Temp & Humidity -10 ~ +50; 20% ~ 90%RH
Storage Temp & Humidity -20 ~ +85; 10% ~ 95%RH
Vibration 10~500Hz, 2G 10min./1cycle, period for 60min, each along X.Y.Z axes
Safety Withstand Voltage I/P-O/P1.5KVAC
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG500VDC/100MΩ
Standards Safety Standards Design refers to UL1012
EMC Standards
Others Weight 0.4Kg
Packing 45pcs/19Kg/1.2CUFT

This product has high safety and is suitable for use in high humidity, high dust, and strong vibration environments.

We make transformers and power inductors with pure coppers all by ourselves.

This product can input 90~132VAC or 180~264VAC through the switch.

This product adopts a long-life design, with a normal life of up to 60,000 hours.

We are a power supply manufacturer with 15 years of experience.

This product has a minimum order quantity of 100 pieces and can be customized with labels.

This product has a universal AC input that is full range (up to 264VAC).

The product has completed the 100% full load aging test.
