Manufacturer in China 60W Quad output switching power supply 220v to 12v

WeHo’s Q-60 Series is a AC/DC multi-output Power supplies  which  standard models that offer.

Q-60  that are available  multiple output supply that can be configured into  many combinations and up to  4 outputs.

WeHo focus on producing high quality power adapters, stable output.

They are highly flexible and compact, fanless power supplies ideal it offers extreme flexibility.

Quick Deliver after putting order, within 3-7 works days for common models

ISOLATION RESISTANGE:I/P-O/P, I/P-FG, O/P-FG:500VDC/100MΩ

Pure copper for transformers coils and power inductor coils

DC VOLTAGEFRE QUENCYRANGE:CH1:+10,-5%

100% aging test before packing

High cost-effective and high safty

Low cost, high reliability

24 months warranty

MODEL Q-60B Q-60C
CH1 CH2 CH3 CH4 CH1 CH2 CH3 CH4
OUTPUT DC VOLTAGE 5V 12V -5V -12V 5V 15V -5V -15V
VOLTAGE TOLERANCE ±2% ±6% ±5% ±5% ±2% ±6% ±5% ±5%
RATED CURRENT 5.5A 2A 0.5A 0.5A 5.5A 1.5A 0.5A 0.5A
CURRENTRANGE 0.5-8A 0.1-3A 0-1A 0-1A 0.5-8A 0.1-3A 0-1A 0-1A
RATED POWER 60W 60W 60W 60W 65W 65W 65W 65W
RIPPLE &NOISE(MAX) 100mVp-p 120mVp-p 100mVp-p 120mVp-p 100mVp-p 120mVp-p 100mVp-p 120mVp-p
DC VOLTAGEFRE QUENCYRANGE CH1:+10,-5%
SETUP,RISE,HOLD TIME 1.6ms,20ms,12ms/115VAC800ms,20ms, 60ms/230VAC
INPUT VOLTAGERANGE 85~264 VAC47-63Hz;20~370VDC
AC CURRENT 1.3A/115 V0.8A/ 230 V
EFFICIENCY 70%
INRUSH CURRENT Cold start 18A/115V36A/230V
PROTECTION OVERLOAD PROTECTION 150%~200% /115VAC Shut down O/P voltage, re-power on to recover
OVER-VOLTAGE PROTECTION CH1:5.75~6.75V
ENVIRONMENT WORKING TEMP.& HUMIDITY -10°C~+50°C;20%~90 %RH
STORAGE TEMP.& HUMIDITY -20°C~+85°C;10%~95 %RH
VIBRATION 10~500Hz,2G 10min./1cycle, period for 60min, each along X.Y.Z axes
SAFETY WITHSTAND VOLTAGE I/P-O/P:3KVACI/P-FG:0.5KVACO/P-FG:0.5KVAC
ISOLATION RESISTANGE I/P-O/P, I/P-FG, O/P-FG:500VDC/100MΩ
STANDARDS SAFETY STANDARDS Design refer to UL1950
EMC STANDARDS Design refer to EN55022,EN55024,EN61000, IEC801-2,3,4IEC555-2
OTHERS WEIGHT 0.56Kg
PACKING 30pcs/ctns
