Different types T-120w multiple power supply triple output

WeHo’s T-120 Series is an AC/DC multi-output Power supply that standard models offer the most cost-effective option when multiple voltages are required.

Input Voltage of T-120: 110V/220 V AC range selectable by the switch,

T-120 is a reliable switching power supply with high-quality material, durable, and safe to use.

If you have any questions, please do not hesitate to contact us at Email: [email protected].

Download Request A Quote

Description

Specifications&Model

Model	T-120A			T-120B			T-120C
Model	CH1	CH2	CH3	CH1	CH2	CH3	CH1	CH2	CH3
DC Output Voltage	5V	12V	-5V	5V	12V	-12V	5V	15V	-15V
Rated Output Current	2-11A	0.5-5A	0.3-1A	2-11A	0.5-4.5A	0.2-1A	2-10A	0.5-3.5A	0.1-1A
Wave And Noise(Note:3)	80mVp-p	150mVp-p	150mVp-p	80mVp-p	150mVp-p	150mVp-p	80mVp-p	150mVp-p	150mVp-p
Inlet Stability(Note:4)	±0.5%	±1%	±1%	±0.5%	±1%	±1%	±0.5%	±1%	±1%
Load Stability(Note:5)	±1%	±5%	±5%	±1%	±5%	±5%	±1%	±6%	±6%
Efficiency	77%			77%			76%
Adjustable Range For DC Voltage	±10%	±5%	±5%	±10%	±5%	±5%	±10%	±5%	±5%
Input Current	90-132VAC/180-264VAC BY SWITCH 254-370VAC 47-63Hz
AC Inrush Current	Cold-start current 30A/115V 60A/230V
Leakage current	<1mA/240VAC
Overload Protection	105%~150% Type: pulsing hiccup shutdown Reset: auto-recovery
Temperature Coefficient	±0.03%/°c(0~50°c)ON+5V
Setup, Rise, Hold Up Time	200ms, 50ms, 16ms/230VAC at full load
Vibration	10~500Hz, 2G 10min,/1cycle, Period for 60min, Each axes
Withstand Voltage	Input and output internal: Input and enclosure: 1.5KvAC Output and enclosure: 0.5KvAC 1 minute
Isolation Resistance	Input and output internal: Input and enclosure Output and enclosure: 500VDC/100MΩ
Safety Standards	CSA international mark approved (CSA950, UL 1950, IEC950, EN60950)
EMC Standards	CISPR22(EN55022), IEC801-2, -3, -4, IEC555-2 Verification
