Ultra Thin LED Lighting Transformers 100W DC 12V 24V Power Supply

Wide Temperature Range: Designed to operate over a wide temperature range, making it suitable for installation in different climates and environments.

Smart Integration: Compatible with smart home systems or IoT platforms to enhance control and automation of lighting settings.

Multiple Output Channels: Transformers with multiple output channels can power different LED fixtures or lighting areas simultaneously.

Compact and Lightweight: The transformer’s compact, lightweight design makes it easy to handle and install, especially in areas with limited space.

Versatile Mounting Options: Offers multiple mounting options such as wall mount or surface mount to accommodate different mounting preferences.

Comprehensive Warranty: Some transformers come with a comprehensive warranty to give you peace of mind and guarantee product reliability.

Compatible with a Variety of LED Fixtures: Designed to work seamlessly with different types of LED fixtures, including strips, bulbs, and panels.

Ultra Thin LED Lighting Transformers 100W DC 12V 24V Power Supply – WL-36W Series

WL-36W Series – Ultra Thin LED Lighting Transformers 100W DC 12V 24V Power Supply, designed to power efficient and versatile LED lighting systems. The transformer features an ultra-thin and space-saving design, making it ideal for installations with limited space. It has a high power output of 100W and is suitable for driving LED lamps and fixtures with lower to medium power requirements.

Key Advantages:

Efficient Power Conversion:

Convert input power to output power with high efficiency, improving energy efficiency and minimizing heat generation.

Cooling Mechanisms:

Effective heat dissipation methods, such as aluminum enclosures or cooling fans, help maintain safe operating temperatures.

Versatile Applications:

Suitable for a variety of LED lighting setups, including residential, commercial, and industrial applications.

Compact Remote Control:

Compact and easy-to-use remote control for conveniently adjusting lighting settings from a distance.

Dimming Compatibility:

Some models may offer dimming functionality, allowing the user to adjust the brightness of connected LED lights.

Long Life:

Quality construction and components help extend service life and reduce the need for frequent replacements.

Comply with Standards:

Comply with international safety and environmental standards to ensure product reliability.

If you have any questions, please do not hesitate to contact us at Email: [email protected].

Model 12V 100W 24V 100W
Output Rated Voltage 12V 24V
Rated Current 8.5A 4.2A
Output Voltage Range 11.8-12.2V 23.6-24.1V
Rated Power 100W 100W
Efficiency >86.5% >89%
Ripple And Noise <180mV <180mV
Load Adjustment Rate 1%
Liner Adjustment Rate 1%
Input Input Voltage Range 110~265V AC
AC Input Current 1.2A 230V
PF Value >0.65
Frequency Range 50-60Hz
Cold Start Current 20A/230VAC
Power Protection If the voltage exceeds 105% of the rated output power, the circuit will automatically reduce the output voltage.
Short Circuit Protection In hiccup mode, it can resume normal operation once the abnormal condition has been rectified.
Environment Operating Temperature, Humidity -40℃~ +70℃   20%~90%RH
Storage Temperature, Humidity -40℃~85℃   10%~95%RH
Safety Regulations Withstand Voltage Performance I/P-O/P: AC2.5KV  5mA 60S;
I/P-FG: AC2KV 5mA 60S
Insulation Impedance I/P-O/P: 100M ohms/500VDC/25℃
Packing Product Dimension 138*50*23mm
N.W 0.2kg
Amount/G.W/Dimension 126PCS/25kg/460*340*185mm
